Product Description
Single phase input
230 V +15% / -20%
50/60 Hz
Fuse rating (slow blow) 16 A
Input power
5,5 kVA 20%
3,7 kVA 60%
2,7 kVA 100%
min - max current
obtainable in welding
20 ÷ 185 A
Duty Cycle (10 min.40°C)
According to IEC 60974-1
185 A 20%
140 A 60%
110 A 100%
Stepless regulation Electronic
Max. wire spool size Ø 200 mm / 5 kg
Protection class IP 23 S
Weight 13,5 kg
Dimensions (WxLxH) 196 x 458 x 380 mm
